Hew Heinz Eilentropp SIFF Series Red 0.52 mm² Hook Up Wire, 20 AWG, 270/0.05 mm, 20m, Silicone Insulation
Technical Document
Specifications
Brand
Hew Heinz EilentroppCross Sectional Area
0.52 mm²
Sheath Colour
Red
American Wire Gauge
20 AWG
Cable Shape
Single Core
Core Strands
270/0.05 mm
Length
20m
Insulation material
Silicone
Voltage Rating
1 kV
Outer Diameter
2.6mm
Maximum Operating Temperature
+180°C
Minimum Operating Temperature
-50°C
Conductor Material
Copper
Series
SIFF
Insulation Wall Thickness
0.8mm
Size of Strands
0.05 mm
Number of Strands
270
Country of Origin
Germany
Product details
SIFF silicone conductor strand, 0.5 mm²
Silicone-insulated stranded cables
Notch-resistant insulation
Highly twisted copper stranded conductors
Particularly well-suited to test leads
High flexibility, maintained within a temperature range of -50°C → +180°C
Highly resistant to contact with soldering irons
P.O.A.
1
P.O.A.
1
Stock information temporarily unavailable.
Please check again later.
