ifm electronic IA5062 Threaded Barrel Proximity Sensor, M16 x 1.5 PNP IA5062 36V 10 mm 36 V dc 250 mA
Technical Document
Specifications
Brand
ifm electronicThread Size
M16 x 1.5
Product Type
Proximity Sensor
Body Style
Threaded Barrel
Length
92mm
IP Rating
IP65
Mount Type
Non-Flush
Maximum Supply Voltage
36V
Housing Material
Polybutylene Terephthalate
Maximum DC Voltage
36V dc
Maximum Detection
10mm
Minimum Operating Temperature
-25°C
Maximum Operating Temperature
80°C
Standards/Approvals
EMC EN 60947-5-2 class B EN 55011
Maximum Switching Frequency
300Hz
Shielding
Unshielded
Series
IA5062
Output Type
PNP
Country of Origin
Romania
Product details
Ø 20 mm and 34 mm
Switching distance 10 mm (nb) for Ø 20 mm type
Switching distance 20 mm (nb) for Ø 34 mm type
AC / DC types for direct and alternating voltage
N/O / N/C output function programmable for AC / DC types
Cable outlet can be mounted straight or angled at 90°
Connection via connection terminals
Type Ø 20 mm DC also available with 2 m PVC cable
Fixing bracket included
