Intersil HIP4082IBZ Quad MOSFET Power Driver, 1.25A 16-Pin, SOIC

RS Stock No.: 496-818Brand: IntersilManufacturers Part No.: HIP4082IBZ
brand-logo
View all in Gate Drivers

Technical Document

Specifications

Brand

Intersil

Pin Count

16

Package Type

SOIC

Number of Outputs

4

High and Low Sides Dependency

Independent

Number of Drivers

4

Bridge Type

Full Bridge

Mounting Type

Surface Mount

Product details

Half Bridge, Full Bridge and Three Phase Drivers, Intersil

Voltage up to 100 V
High Performance Input-to-Output Propagation Delay

MOSFET & IGBT Drivers, Intersil

Ideate. Create. Collaborate
