Grey Button Tactile Switch, SPST 50 mA @ 24 V dc 6.8mm

RS Stock No.: 682-1345Brand: OmronManufacturers Part No.: B3J-5000
brand-logo
View all in Tactile Switches

Technical Document

Specifications

Brand

Omron

Contact Configuration

SPST

Terminal Type

Through Hole

Actuator Length

6.8mm

Actuator Colour

Grey

Actuator Type

Button

Illuminated

Yes

Contact Current Rating

50 mA @ 24 V dc

Operating Force

1.27 N

PRICED TO CLEAR

Yes

Country of Origin

Japan

Product details

Tactile Switches Omron B3J

Hinged type tactile switch
Quick superior snap-action through hook-type hinge construction
Available with 1 or 2 LED's or without LED's
The hinge button is available in a variety of five standard colours
Contact Form SPST- NO
Maximum switching capacity 50 mA @ 24 Vdc
