Panasonic Timer Relay, 100 → 120V ac, 2-Contact, 1 → 10s, 1-Function, DPDT
Technical Document
Specifications
Brand
PanasonicSupply Voltage
100 → 120V ac
Time Range
1 → 10s
Number of Contacts
2
Number of Timer Functions
Single
Contact Configuration
DPDT
Time Increment
Seconds
Switch Configuration
DPDT
Power Supply
External
Width
72.5mm
Length
48mm
Maximum Operating Temperature
+50°C
Depth
48mm
Contact Material
Silver Alloy
Minimum Operating Temperature
-10°C
Time Delay
100ms
Country of Origin
Japan
Product details
Power Off-Delay Timer Relay, PM4HF8
Premium quality Off-Delay timer relay which is cost effective without sacrificing on performance or function
Features of the PM4HF8 Series
Three switching operation times available, ranging from 1 second to 10 minutes
Instantaneous reset available
Easier to use and install thanks to a shorter timer body
Standards
Compliant with UL, CSA, CE and LLOYD
