Technical Documents
Specifications
Brand
MicrochipProduct Type
Complex Programmable Logic Device
Series
ATF15xx
Number of Macro Cells
128
Number of User I/Os
80
Maximum Propagation Delay Time
7.5ns
Memory Type
EEPROM
Number of Logic Blocks/Elements
14
In System Programmability
Yes
Mount Type
Surface
Package Type
TQFP
Minimum Supply Voltage
4.75V
Pin Count
100
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Maximum Supply Voltage
5.25V
Individual Output Enable Control
Yes
Height
1.05mm
Length
14.1mm
Standards/Approvals
No
Maximum Operating Frequency
125MHz
Re-programmability Support
Yes
Automotive Standard
No
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
P.O.A.
Each (In a Tray of 90) (Exc. Vat)
90
P.O.A.
Each (In a Tray of 90) (Exc. Vat)
Stock information temporarily unavailable.
90
