STMicroelectronics 170 V 8 A Diode Schottky 8-Pin PowerFLAT STPS8170DEE-TR

RS Stock No.: 829-0377Brand: STMicroelectronicsManufacturers Part No.: STPS8170DEE-TR
brand-logo
View all in Schottky Diodes & Rectifiers

Technical Document

Specifications

Brand

STMicroelectronics

Product Type

Diode

Mount Type

Surface

Package Type

PowerFLAT

Maximum Continuous Forward Current If

8A

Peak Reverse Repetitive Voltage Vrrm

170V

Diode Configuration

Single

Series

STPS8170DEE

Rectifier Type

Schottky

Pin Count

8

Peak Reverse Current Ir

15mA

Maximum Forward Voltage Vf

900mV

Minimum Operating Temperature

-65°C

Peak Non-Repetitive Forward Surge Current Ifsm

100A

Maximum Operating Temperature

175°C

Width

3.4 mm

Length

3.4mm

Height

1.05mm

Standards/Approvals

No

Automotive Standard

No

Product details

Schottky Barrier Diodes, 2A to 9A, STMicroelectronics

Diodes and Rectifiers, STMicroelectronics
